| Item | Parameter |
| Effective Lamination Area | 2700*8700mm |
| Capacity | 250-300MW/year |
| Uptime | ≥99.5% |
| Vacuum Degree | 30pa |
| Temperature Range | room temperature-180℃ |
| Precision of Temperature Control（°C） | ±1.5℃ |
| Temperature Accuracy（°C） | ±1℃ |
| Heating Mode | Oil heating/electric heating |
| Cooling Mode | fan cooling |
| Compressed Air Pressure(Mpa) | 0.6-0.8mpa |
| Dimensions (mm) | 47700*3650*3600mm |
2. Equipment Features of Double Layer&Triple Chamber Laminator
1) The third chamber applies the rapid circulation of cooling water to help the moduless cool down quickly
2) Efficient cleaning system, intelligent control mode, realize unmanned lamination
3) Conducive to the cleaning of stains with circulating high temperature cloth
4) Strong compatibility, suitable for a variety of module production
5) The upper and lower layers are independently transmitted without interfering with each other; each layer is linked with three levels, integrated synchronous transmission, more stable and reliable
6) It can effectively reduce the warpage of pv modules，meanwhile reduce the generation of poor component framing
7) Other dimensions are also available according to customer's request.
